H300 Series
Adapter
Shaft d1
Dimensions(mm)
Weight
Composition
Sleeve
HS
HA
HE
H
d
d2
B1
B2
G
Kg
Sleeve
Locknut
Lockwasher
No.
in
in
in
mm
≈
H304
　
　
　
17
20
32
28
7
M20x1
0.045
A304
KM4
MB04
H305
7/8
13/16
3/4
20
25
38
29
8
M25x1.5
0.075
A305
KM5
MB05
H306
7/8
15/16
1
25
30
45
31
8
M30x1.5
0.11
A306
KM6
MB06
H307
1-1/8
1-3/16
1-1/4
30
35
52
35
9
M35x1.5
0.14
A307
KM7
MB07
H308
1-3/8
1-5/16
1-1/4
35
40
58
36
10
M40x1.5
0.19
A308
KM8
MB08
H309
1-5/8
1-7/16
1-1/2
40
45
65
39
11
M45x1.5
0.25
A309
KM9
MB09
H310
1-5/8
1-11/16
1-3/4
45
50
70
42
12
M50x1.5
0.3
A310
KM10
MB10
H311
1-7/8
1-15/16
2
50
55
75
45
12
M55x2
0.35
A311
KM11
MB11
H312
2-1/8
2-1/16
2-1/4
55
60
80
47
13
M60x2
0.39
A312
KM12
MB12
H313
2-3/8
2-3/16
2-1/4
60
65
85
50
14
M65x2
0.46
A313
KM13
MB13
H314
　
　
　
60
70
92
52
14
M70x2
0.72
A314
KM14
MB14
H315
2-5/8
2-7/16
2-1/2
65
75
98
55
15
M75x2
0.83
A315
KM15
MB15
H316
2-7/8
2-11/16
2-3/4
70
80
105
59
17
M80x2
1
A316
KM16
MB16
H317
　
2-15/16
3
75
85
110
63
18
M85x2
1.2
A317
KM17
MB17
H318
3-1/8
3-3/16
3-1/4
80
90
120
65
18
M90x2
1.35
A318
KM18
MB18
H319
　
3-5/16
3-1/4
85
95
125
68
19
M95x2
1.55
A319
KM19
MB19
H320
　
3-7/16
3-1/2
90
100
130
71
20
M100x2
1.7
A320
KM20
MB20
H321
　
　
　
95
105
140
74
20
M105x2
1.95
A321
KM21
MB21
H322
　
3-15/16
4
100
110
145
77
21
M110x2
2.2
A322
KM22
MB22
